Description
Experience the freedom of walkaway automation with the Thermo Scientific™ Gallery™ Aqua Master, a fully automated, discrete photometric analyzer for water, nutrient and agricultural testing. This system generates fast, reproducible results in a compact, benchtop design and can run different analyses simultaneously from a single sample to help reduce total analysis time and cost. Combining rugged hardware and custom-designed software, Gallery Aqua Master helps you meet regulatory method requirements while automating complicated calibration sequences, quality control, and spiking procedures.
Automated operation and reliable technology
- Advanced software features including choice of calibration order, relative standard error calculation, automated spiking procedures, automated QC procedures, flexible reporting, and smart suggested dilutions
- Automated water and nutrient analysis workflows that meet U.S. EPA guidelines and other local regulations
- Continuous access to samples, reagents, and cuvettes without interruption of routine workflows
- Integrated platform for simultaneous photometric and electrochemical analysis
- Automates all required analysis steps, enabling up to 2 hours of walkaway time and reducing manual errors
- Standard throughput with a sample capacity of up to 200 tests/hour
Robust capabilities
- Combined sample and reagent disk with up to 90 sample positions on board
- Detection levels in the ppb range with excellent reproducibility
- Twelve filter positions and wavelength range from 340 nm to 880 nm
- Long-life xenon light source good for years of operation
- Disposable cuvettes minimize potential for contamination
- Low maintenance with less than one service visit required per year, on average
Versatile and economical
- Ready-to-use system reagents eliminate time-consuming reagent preparation
- Uniquely low-volume cuvettes for lowest reagent consumption and waste and up to 20 times lower operating costs
- Open system allows you to modify an existing method or create your own test, and adopt 3rd party reagents
User-friendly operation
- Suitable for all user expertise levels with minimal training required
- Automatic startup and shutdown protocols
- Self-contained benchtop for small footprint
Specifications
| Analytical Method | Discrete Analysis |
| Description | Gallery™ Aqua Master without ECM Unit |
| Dimensions (D x W x H) | 70 x 75 x 62/130 cm (cover closed/cover open) |
| Electrochemistry Unit (ECM) | Optional |
| For Use With (Application) | Water Analysis, Nutrient Analysis, Environmental Testing, Industrial Water Testing, Agricultural Testing |
| Incubation Temperature | 25°C to 60°C |
| Measurement Method | Photometric: 340 nm–880 nm pH Range: 3–7.2 |
| Reagent Capacity | Up to 30 |
| Sample Size | 45–90 samples |
| Throughput | 200 Photometric Tests/h |
| Weight (Metric) | 85 kg |
| Type | Discrete Analyzer |
| Unit Size | Each |
